Fitting a VGG-16 network on CIFAR-10 for image classification! We use gradient clipping for faster convergence.
编辑来源网络
import tensorflow as tf
from tensorflow import keras
from tensorflow.keras import datasets, layers, optimizers, models
from tensorflow.keras import regularizers
class VGG16(models.Model):
def __init__(self, input_shape):
"""
:param input_shape: [32, 32, 3]
"""
super(VGG16, self).__init__()
weight_decay = 0.000
self.num_classes = 10
model = models.Sequential()
model.add(layers.Conv2D(64, (3, 3), padding='same',
input_shape=input_shape, kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.3))
model.add(layers.Conv2D(64, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.MaxPooling2D(pool_size=(2, 2)))
model.add(layers.Conv2D(128, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(128, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.MaxPooling2D(pool_size=(2, 2)))
model.add(layers.Conv2D(256, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(256, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(256, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.MaxPooling2D(pool_size=(2, 2)))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.MaxPooling2D(pool_size=(2, 2)))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.4))
model.add(layers.Conv2D(512, (3, 3), padding='same',kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.MaxPooling2D(pool_size=(2, 2)))
model.add(layers.Dropout(0.5))
model.add(layers.Flatten())
model.add(layers.Dense(512,kernel_regularizer=regularizers.l2(weight_decay)))
model.add(layers.Activation('relu'))
model.add(layers.BatchNormalization())
model.add(layers.Dropout(0.5))
model.add(layers.Dense(self.num_classes))
# model.add(layers.Activation('softmax'))
self.model = model
def call(self, x):
x = self.model(x)
return x
import os
import tensorflow as tf
from tensorflow import keras
from tensorflow.keras import datasets, layers, optimizers
import argparse
import numpy as np
from network import VGG16
os.environ['TF_CPP_MIN_LOG_LEVEL'] = '2' # or any {'0', '1', '2'}
argparser = argparse.ArgumentParser()
argparser.add_argument('--train_dir', type=str, default='/tmp/cifar10_train',
help="Directory where to write event logs and checkpoint.")
argparser.add_argument('--max_steps', type=int, default=1000000,
help="""Number of batches to run.""")
argparser.add_argument('--log_device_placement', action='store_true',
help="Whether to log device placement.")
argparser.add_argument('--log_frequency', type=int, default=10,
help="How often to log results to the console.")
def normalize(X_train, X_test):
# this function normalize inputs for zero mean and unit variance
# it is used when training a model.
# Input: training set and test set
# Output: normalized training set and test set according to the trianing set statistics.
X_train = X_train / 255.
X_test = X_test / 255.
mean = np.mean(X_train, axis=(0, 1, 2, 3))
std = np.std(X_train, axis=(0, 1, 2, 3))
print('mean:', mean, 'std:', std)
X_train = (X_train - mean) / (std + 1e-7)
X_test = (X_test - mean) / (std + 1e-7)
return X_train, X_test
def prepare_cifar(x, y):
x = tf.cast(x, tf.float32)
y = tf.cast(y, tf.int32)
return x, y
def compute_loss(logits, labels):
return tf.reduce_mean(
tf.nn.sparse_softmax_cross_entropy_with_logits(
logits=logits, labels=labels))
def main():
tf.random.set_seed(22)
print('loading data...')
(x,y), (x_test, y_test) = datasets.cifar10.load_data()
x, x_test = normalize(x, x_test)
print(x.shape, y.shape, x_test.shape, y_test.shape)
# x = tf.convert_to_tensor(x)
# y = tf.convert_to_tensor(y)
train_loader = tf.data.Dataset.from_tensor_slices((x,y))
train_loader = train_loader.map(prepare_cifar).shuffle(50000).batch(256)
test_loader = tf.data.Dataset.from_tensor_slices((x_test, y_test))
test_loader = test_loader.map(prepare_cifar).shuffle(10000).batch(256)
print('done.')
model = VGG16([32, 32, 3])
# must specify from_logits=True!
criteon = keras.losses.CategoricalCrossentropy(from_logits=True)
metric = keras.metrics.CategoricalAccuracy()
optimizer = optimizers.Adam(learning_rate=0.0001)
for epoch in range(250):
for step, (x, y) in enumerate(train_loader):
# [b, 1] => [b]
y = tf.squeeze(y, axis=1)
# [b, 10]
y = tf.one_hot(y, depth=10)
with tf.GradientTape() as tape:
logits = model(x)
loss = criteon(y, logits)
# loss2 = compute_loss(logits, tf.argmax(y, axis=1))
# mse_loss = tf.reduce_sum(tf.square(y-logits))
# print(y.shape, logits.shape)
metric.update_state(y, logits)
grads = tape.gradient(loss, model.trainable_variables)
# MUST clip gradient here or it will disconverge!
grads = [ tf.clip_by_norm(g, 15) for g in grads]
optimizer.apply_gradients(zip(grads, model.trainable_variables))
if step % 40 == 0:
# for g in grads:
# print(tf.norm(g).numpy())
print(epoch, step, 'loss:', float(loss), 'acc:', metric.result().numpy())
metric.reset_states()
if epoch % 1 == 0:
metric = keras.metrics.CategoricalAccuracy()
for x, y in test_loader:
# [b, 1] => [b]
y = tf.squeeze(y, axis=1)
# [b, 10]
y = tf.one_hot(y, depth=10)
logits = model.predict(x)
# be careful, these functions can accept y as [b] without warnning.
metric.update_state(y, logits)
print('test acc:', metric.result().numpy())
metric.reset_states()
if __name__ == '__main__':
main()
😱😱😱😱
